PSG-2 Bluetooth/GSM Surface Recorder

With our PSG-2 model you will have access to your transmitted data and access to all your sample and configurations settings via a secure remote connection from your PSG-2 surface recorder to your Dashboard web app from any local GSM cellular network. The PSG-2 digital surface recorder was designed with your safety in mind. With our Live Bluetooth Mode you will also be able to access and download your real time date from the PSG-2 surface recorder from a safe local distance of 100 meters, keeping you out of harms way. Our PSG-2 digital pressure memory recorder has a built in Live Bluetooth Mode that will enable you to connect directly to any Bluetooth enabled Windows laptop, Android tablet or mobile device.
North America Certified for Class I/Div I as well as Class I/Zone I applications.
ATEX certified for Class 1/Zone 1.
Access your data via our online Dashoard Web App through any Worldwide GSM cellular network.
Access Bluetooth Wireless communication from up to 100m with any Android device and windows computer with a USB Dongle.
The PSG-2 Surface Recorder uses a single Lithium or Alkaline D-Cell as its primary power source.
The PSG-2 utilizes the same Flash drive based USB communication as our Vector Downhole gauges.
Has a built in low power consumption back lit LCD display.
User has many programmable options to optimize the battery life on their PSG Recorder.
Specifications:
Accuracy0.05% F.S. - 0.3 °C
Resolution0.0003% F.S. - 0.01 °C
Drift/Year<2.9psi Per Year - <0.1 °C
TransducerPiezo-Resistive Silicon
Memory Capacity16 Million Samples
Sample Rate1 Second to 18 Hours
Housing MaterialLow Copper Aluminum Alloy
Pressure Sensor316 L Stainless Steel
Pressure RangesTemperature Ranges
3,000 psi (20,684 kpa)-30°C to 85°C
6,000 psi (41,368 kpa)-30°C to 85°C
10,000 psi (68,497 kpa)-30°C to 85°C
Communication:
USBYes - Windows XP and Later
BluetoothYes - 100 Meter Range
Cellular (GSM)Yes - Sim Card Not Included
GPSNo - Only Available in PSG-3 Models
Certifications and Standards:
North America DivisionsClass | Division 1, Groups C & D, T5
North America ZonesClass | Division 1, Group IIB, T5
Conforms to StandardsUL-61010 & UL-1203
Certified toCAN/CSA C22.2 No. 61010
Certified toCAN/CSA C22.2 No. 30
Power Supply:
Lithium CellAlkaline Cell
Cell ManufactureSaftEnergizer or Duracell
Cell Part #
LS33600E95 or MN1300
Voltage3.67 Volts1.5 Volts
Battery Life6 to 8 Months3 to 5 Months
Dangerous GoodsYes (UN3091, Class 9)No
Min Temp-40°C (-40°F)-18°C (0°F)
Max Temp85°C (185°F)55°C (130°F)
Mechanical:
Gauge Height13.0" (330 mm)
Gauge Width4.0" (102 mm)
Gauge Weight5.5 lbs (2.5 kg)
Inlet TypeHF6 (3/8" HP Tube Fitting)
Inlet Adapter1/2" NPT
