PSG-1(E) Bluetooth Surface Recorder

The PSG-1(E) digital surface recorder was designed with your safety in mind. With our Live Bluetooth Mode you can now access and download your real time date from the PSG-1(E) surface recorder at a safe distance 100m, keeping you out of harms way. Our PSG-1(E) digital pressure memory recorder has a built in Live Bluetooth Mode that will enable you to connect directly to any Bluetooth enabled Windows laptop, Android tablet or mobile device.
North America Certified for Class I/Div I as well as Class I/Zone I applications.
ATEX certified for Class 1/Zone 1.
Access Bluetooth Wireless communication from up to 100m with any Android device and windows computer with a USB Dongle.
The PSG-1 Surface Recorder uses a single Lithium or Alkaline D-Cell as its primary power source.
The PSG-1 utilizes the same Flash drive based USB communication as our Vector Downhole gauges.
Has a built in low power consumption back lit LCD display.
User has many programmable options to optimize the battery life on their PSG Recorder.
Specifications:
Accuracy0.05% F.S. - 0.3 °C
Resolution0.0003% F.S. - 0.01 °C
Drift/Year<2.9psi Per Year - <0.1 °C
TransducerPiezo-Resistive Silicon
Memory Capacity16 Million Samples
Sample Rate1 Second to 18 Hours
Housing MaterialLow Copper Aluminum Alloy
Pressure Sensor316 L Stainless Steel
Pressure RangesTemperature Ranges
3,000 psi (20,684 kpa)-30°C to 85°C
6,000 psi (41,368 kpa)-30°C to 85°C
10,000 psi (68,497 kpa)-30°C to 85°C
Communication:
USBYes - Windows XP and Later
BluetoothYes - 100 Meter Range
Cellular (GSM)No - Only Available in PSG-2 Models
GPSNo - Only Available in PSG-3 Models
Certifications and Standards:
North America DivisionsClass | Division 1, Groups C & D, T5
North America ZonesClass | Division 1, Group IIB, T5
Conforms to StandardsUL-61010 & UL-1203
Certified toCAN/CSA C22.2 No. 61010
Certified toCAN/CSA C22.2 No. 30
Power Supply:
Lithium CellAlkaline Cell
Cell ManufactureSaftEnergizer or Duracell
Cell Part #
LS33600E95 or MN1300
Voltage3.67 Volts1.5 Volts
Battery Life6 to 8 Months3 to 5 Months
Dangerous GoodsYes (UN3091, Class 9)No
Min Temp-40°C (-40°F)-18°C (0°F)
Max Temp85°C (185°F)55°C (130°F)
Mechanical:
Gauge Height13.0" (330 mm)
Gauge Width4.0" (102 mm)
Gauge Weight5.5 lbs (2.5 kg)
Inlet TypeHF6 (3/8" HP Tube Fitting)
Inlet Adapter1/2" NPT
